Key features
- Innovative, lightweight wheelchair base
- Highly manoeuvrable design
- Compatible with both R82 Panda Futura and x:panda seats
- Can also accommodate other manufacturers seating with similar construction and meeting safety standards
- Simple tilt-in-space function with minimal moving parts
- Compliant with ISO 7176-19 for transporting users in motor vehicles
Specifications
| Code(s) | 0500-97111011 | 0500-97211011 |
| Size 1 | Size 2 | |
| Size | 1 | 2 |
| Inside back width | 245mm | 295mm |
| Folded height with 12.5" back wheels | 470mm | 470mm |
| Folded height with 22" back wheels | 560mm | 560mm |
| Folded height without back wheels - Mid position | 400mm | 400mm |
| Folded length with 12.5" back wheels | 730mm | 730mm |
| Folded length with 22" back wheels | 850mm | 850mm |
| Folded length with 22" wheels | 850mm | 850mm |
| Footrest to adaptor plate | 50 - 340mm | 50 - 340mm |
| Hand brace length | 225mm | 225mm |
| Handrim diameter | 480mm | 480mm |
| Inside width | 340mm | 390mm |
| Length with 12.5" wheels | 640mm | 640mm |
| Length with 22" wheels | 750mm | 750mm |
| Overall height push brace 15° | 915mm | 915mm |
| Overall height push brace 30° | 850mm | 850mm |
| Overall width 22" wheels and drumbrake | 430mm | 480mm |
| Overall width with 12.5" wheels | 590mm | 640mm |
| Overall width with 22" wheels | 590mm | 640mm |
| Seat plane angle | 0 - 30, 35, 40° | 0 - 30, 35, 40° |
| Seat surface height at front edge | 395, 425, 455mm | 395, 425, 455mm |
| Width between 22" wheels with drum brake | 430mm | 480mm |
| Width between 22" wheels without drum brake | 440mm | 490mm |
| Width inside | 340mm | 390mm |
| Product weight with 12.5" wheels | 13kg | 13kg |
| Product weight with 22" wheels | 14kg | 14kg |
| Max. user weight | 100kg | 100kg |
| Safe working load | 115kg | 115kg |
Information sheet
Key features
- Innovative, lightweight wheelchair base
- Highly manoeuvrable design
- Compatible with both R82 Panda Futura and x:panda seats
- Can also accommodate other manufacturers seating with similar construction and meeting safety standards
- Simple tilt-in-space function with minimal moving parts
- Compliant with ISO 7176-19 for transporting users in motor vehicles
| Code(s) | 0500-97111011 | 0500-97211011 |
| Size 1 | Size 2 | |
| Size | 1 | 2 |
| Inside back width | 245mm | 295mm |
| Folded height with 12.5" back wheels | 470mm | 470mm |
| Folded height with 22" back wheels | 560mm | 560mm |
| Folded height without back wheels - Mid position | 400mm | 400mm |
| Folded length with 12.5" back wheels | 730mm | 730mm |
| Folded length with 22" back wheels | 850mm | 850mm |
| Folded length with 22" wheels | 850mm | 850mm |
| Footrest to adaptor plate | 50 - 340mm | 50 - 340mm |
| Hand brace length | 225mm | 225mm |
| Handrim diameter | 480mm | 480mm |
| Inside width | 340mm | 390mm |
| Length with 12.5" wheels | 640mm | 640mm |
| Length with 22" wheels | 750mm | 750mm |
| Overall height push brace 15° | 915mm | 915mm |
| Overall height push brace 30° | 850mm | 850mm |
| Overall width 22" wheels and drumbrake | 430mm | 480mm |
| Overall width with 12.5" wheels | 590mm | 640mm |
| Overall width with 22" wheels | 590mm | 640mm |
| Seat plane angle | 0 - 30, 35, 40° | 0 - 30, 35, 40° |
| Seat surface height at front edge | 395, 425, 455mm | 395, 425, 455mm |
| Width between 22" wheels with drum brake | 430mm | 480mm |
| Width between 22" wheels without drum brake | 440mm | 490mm |
| Width inside | 340mm | 390mm |
| Product weight with 12.5" wheels | 13kg | 13kg |
| Product weight with 22" wheels | 14kg | 14kg |
| Max. user weight | 100kg | 100kg |
| Safe working load | 115kg | 115kg |
Information sheet
Accessories
-
![]()
R82 Multiframe foot support rod
- Code(s): 0500-8910821-1
