Key features
- Weight is centered around the rear drive wheels, and with the four wheels, provides improved driving power in more difficult terrain
- Unique suspension on all wheels, providing an extremely smooth ride
- Electric HiLo feature allows the seat to be lowered to a height of 380mm (without the cushion) to fit under any table or desk
- Comes standard with a 300mm electric lift, providing a lifting height of 380-700mm that offers improved access to higher counters and cabinets
- With the Dahl Docking System or the 4 Point Tie Down System, TA Electric wheelchairs may be used as a seat in a car, avoiding the need to relocate to a car seat
- Inside a car, the lower seat height improves vision and headroom
- Electric 300mm HILo elevate, 45 °tilt function are standard
- Option power tilt -4 to 24°
- Longer range up to 40km
- Crash tested for vehicle occupancy
Specifications
| Code(s) | XTAIQRWD02 |
| Tilt/ elevate | |
| Seat plate to floor max. height | 680 - 730mm/ 27-29" |
| Seat plate to floor min. height | 380 - 430mm/15 - 17" |
| Back recline | 50° manual or electric |
| Seat tilt | 45° electric |
| Seat lift | 300mm/ 12" electric |
| Legrest | Centre Manual. Optional: Central electric, Swing-away manual or electric |
| Turning radius | 650mm/ 25.5" |
| Chair width | 600 - 630mm/ 25" |
| Chair length without footrests | 915mm/ 36" |
| Range max. | 40km |
| Speed max. | 12.5km/h |
| Max. user weight | 140kg |
| Motor type | 4 Pole |
| Battery size | 80Ah x 2 |
| Weight | 140kg |
| Seat width | 370 - 550mm/ 14.5 - 21.5" |
| Backrest width | 370 - 550mm/ 14.5 - 21.5" |
| Seat depth | 350 - 550mm/ 14 - 22" |
Information sheet
Key features
- Weight is centered around the rear drive wheels, and with the four wheels, provides improved driving power in more difficult terrain
- Unique suspension on all wheels, providing an extremely smooth ride
- Electric HiLo feature allows the seat to be lowered to a height of 380mm (without the cushion) to fit under any table or desk
- Comes standard with a 300mm electric lift, providing a lifting height of 380-700mm that offers improved access to higher counters and cabinets
- With the Dahl Docking System or the 4 Point Tie Down System, TA Electric wheelchairs may be used as a seat in a car, avoiding the need to relocate to a car seat
- Inside a car, the lower seat height improves vision and headroom
- Electric 300mm HILo elevate, 45 °tilt function are standard
- Option power tilt -4 to 24°
- Longer range up to 40km
- Crash tested for vehicle occupancy
| Code(s) | XTAIQRWD02 |
| Tilt/ elevate | |
| Seat plate to floor max. height | 680 - 730mm/ 27-29" |
| Seat plate to floor min. height | 380 - 430mm/15 - 17" |
| Back recline | 50° manual or electric |
| Seat tilt | 45° electric |
| Seat lift | 300mm/ 12" electric |
| Legrest | Centre Manual. Optional: Central electric, Swing-away manual or electric |
| Turning radius | 650mm/ 25.5" |
| Chair width | 600 - 630mm/ 25" |
| Chair length without footrests | 915mm/ 36" |
| Range max. | 40km |
| Speed max. | 12.5km/h |
| Max. user weight | 140kg |
| Motor type | 4 Pole |
| Battery size | 80Ah x 2 |
| Weight | 140kg |
| Seat width | 370 - 550mm/ 14.5 - 21.5" |
| Backrest width | 370 - 550mm/ 14.5 - 21.5" |
| Seat depth | 350 - 550mm/ 14 - 22" |
