Key features
- High user weight and wide seat for larger/bariatric users
- High-gloss, electro-polished surface that is easy to clean and will not scratch, chip or peel away, and can be disinfected and sanitised with a steam cleaner
- Adjustable headrest for extra support when tilting back
- Add on adjustable tension fabric back upholstery which can be removed for machine washing
- Removable moulded seat, contoured for pressure reduction and pelvic stability for the accessories
- Stainless steel frame and hardware for corrosion resistance in wet environments
- Swing away, adjustable footrests, removable for transfers and cleaning
- Can be adjusted to suit leg lengths without tools
- Ischial Pelvic Alignment System (IPAS) provides 50mm of fore/aft adjustment so the seat can be aligned with the pelvis
- Seat frame tilts 25° for pressure reduction and comfort
- Pressurised springs help lift seat frame to an upright position
- Conveniently located tilt triggers provide smooth tilt control
- Adjustable back angle
Specifications
| Code(s) | 2919 | 2920 |
| Option | W 550mm (22") | W 610mm (24") |
| Product weight | 38kg | 38kg |
| Safe working load | 272kg | 272kg |
| Overall dimensions | W 695mm D 955mm | W 725mm D 1030mm |
| Seat dimensions | W 590mm D 475mm H 750 - 975mm | W 590mm H 552 - 585mm |
| Width between arms | 590mm | 610mm |
| Armrest height | 240mm | 240mm |
| Clearance height | 455 - 480mm | 430 - 455mm |
| Tilt angle | 40° | 40° |
| Braking | Individually braking | Individually braking |
Raz® shower commode - Rationale support guide
Aqua Soft® Information
User manual
Meet the Raz family
![[video thumbnail]](/assets/Thumbnails/Commodes-Image__FocusFillMaxWyIwLjAwIiwiMC4wMCIsMjg1LDE2MF0.jpg)
![[video thumbnail]](/assets/Thumbnails/Video-thumbnails_Website-Resources_Webinars_1920x1080_Optimising-postural-and-pressure-management-in-mobile-shower-commodes-v2__FocusFillMaxWyIwLjAwIiwiMC4wMCIsMjg1LDE2MF0.jpg)
![[video thumbnail]](http://img.youtube.com/vi/2l5fiVaKMWY/mqdefault.jpg)
![[video thumbnail]](/assets/Thumbnails/Video-thumbnails_Website-Resources_List-of-equipment-training_1920x1080_Showering-and-hygiene-solutions-for-bariatric-clients-v4__FocusFillMaxWyIwLjAwIiwiMC4wMCIsMjg1LDE2MF0.jpg)
![[video thumbnail]](/assets/Thumbnails/Raz-commode-seats__FocusFillMaxWyIwLjAwIiwiMC4wMCIsMjg1LDE2MF0.png)
Key features
- High user weight and wide seat for larger/bariatric users
- High-gloss, electro-polished surface that is easy to clean and will not scratch, chip or peel away, and can be disinfected and sanitised with a steam cleaner
- Adjustable headrest for extra support when tilting back
- Add on adjustable tension fabric back upholstery which can be removed for machine washing
- Removable moulded seat, contoured for pressure reduction and pelvic stability for the accessories
- Stainless steel frame and hardware for corrosion resistance in wet environments
- Swing away, adjustable footrests, removable for transfers and cleaning
- Can be adjusted to suit leg lengths without tools
- Ischial Pelvic Alignment System (IPAS) provides 50mm of fore/aft adjustment so the seat can be aligned with the pelvis
- Seat frame tilts 25° for pressure reduction and comfort
- Pressurised springs help lift seat frame to an upright position
- Conveniently located tilt triggers provide smooth tilt control
- Adjustable back angle
| Code(s) | 2919 | 2920 |
| Option | W 550mm (22") | W 610mm (24") |
| Product weight | 38kg | 38kg |
| Safe working load | 272kg | 272kg |
| Overall dimensions | W 695mm D 955mm | W 725mm D 1030mm |
| Seat dimensions | W 590mm D 475mm H 750 - 975mm | W 590mm H 552 - 585mm |
| Width between arms | 590mm | 610mm |
| Armrest height | 240mm | 240mm |
| Clearance height | 455 - 480mm | 430 - 455mm |
| Tilt angle | 40° | 40° |
| Braking | Individually braking | Individually braking |
Raz® shower commode - Rationale support guide
Aqua Soft® Information
User manual
Meet the Raz family
Accessories
-
![Raz<sup>®</sup> pivoting hand grips]()
Raz® pivoting hand grips
- Code(s): 3032
-
![Raz<sup>®</sup> head support pad - Large]()
Raz® head support pad - Large
- Code(s): 2945
-
![Raz<sup>®</sup> commode pan spacer kits]()
Raz® commode pan spacer kits
- Code(s): 2986, 2987, 2988, 2989
-
![Viking<sup>®</sup> padded footplate cover]()
Viking® padded footplate cover
- Code(s): 75FF
-
![Viking<sup>®</sup> commode drop-in urine deflector]()
Viking® commode drop-in urine deflector
- Code(s): 75UD
-
![Raz<sup>®</sup> pivoting arm mount - Right]()
Raz® pivoting arm mount - Right
- Code(s): 2983
-
![Raz<sup>®</sup> pivoting arm mount - Left]()
Raz® pivoting arm mount - Left
- Code(s): 2982
-
![Raz<sup>®</sup> shower commode pan]()
Raz® shower commode pan
- Code(s): 2933
-
![Raz<sup>®</sup> molded seat with open front]()
Raz® molded seat with open front
- Code(s): 2932, 2929
-
![Raz<sup>®</sup> molded flat armpad]()
Raz® molded flat armpad
- Code(s): 2978
-
![Raz<sup>®</sup> molded arm trough - Right]()
Raz® molded arm trough - Right
- Code(s): 2981
-
![Raz<sup>®</sup> molded arm trough - Left]()
Raz® molded arm trough - Left
- Code(s): 2980
-
![Raz<sup>®</sup> lateral support extension plate]()
Raz® lateral support extension plate
- Code(s): 2991
-
![Raz<sup>®</sup> tilt-in-space commode hip adductor kit - Right]()
Raz® tilt-in-space commode hip adductor kit - Right
- Code(s): 2999
-
![Raz<sup>®</sup> elevating legrest - Right]()
Raz® elevating legrest - Right
- Code(s): 2966
-
![Raz<sup>®</sup> elevating legrest - Left]()
Raz® elevating legrest - Left
- Code(s): 2965
-
![Raz<sup>®</sup> directional castor lock for tilt-in-space commode]()
Raz® directional castor lock for tilt-in-space commode
- Code(s): 2973
-
![Raz<sup>®</sup> armrest spacer kit]()
Raz® armrest spacer kit
- Code(s): 2985
-
![Raz<sup>®</sup> Adjusta-back armrest lock kit]()
Raz® Adjusta-back armrest lock kit
- Code(s): 2944
-
![Raz<sup>®</sup> V-style 1-piece footrest]()
Raz® V-style 1-piece footrest
- Code(s): 2967
-
![Raz<sup>®</sup> Tilt-in-space commode leg adductor kit - Left]()
Raz® Tilt-in-space commode leg adductor kit - Left
- Code(s): 2996
-
![Raz<sup>®</sup> molded seat with bridged front]()
Raz® molded seat with bridged front
- Code(s): 2934
-
![Raz lateral support - Right]()
Raz lateral support - Right
- Code(s): 2992
-
![Raz lateral support - Left]()
Raz lateral support - Left
- Code(s): 2990
-
![Raz<sup>®</sup> tilt-in-space commode hip adductor kit - Left]()
Raz® tilt-in-space commode hip adductor kit - Left
- Code(s): 2998
-
![Raz<sup>®</sup> heel loops]()
Raz® heel loops
- Code(s): 2972
-
![Raz H-strap calf support]()
Raz H-strap calf support
- Code(s): 2971
-
![Raz<sup>®</sup> depth adjustable footplate]()
Raz® depth adjustable footplate
- Code(s): 2969
-
![Raz<sup>®</sup> shower only moulded seat]()
Raz® shower only moulded seat
- Code(s): 3000
-
![Raz<sup>®</sup> pommel thigh support]()
Raz® pommel thigh support
- Code(s): 2968
-
![Raz<sup>®</sup> attendant-propelled shower commode - 450mm]()
Raz® attendant-propelled shower commode - 450mm
- Code(s): 2902
