Key features
- Four powered wheels for superior traction and agility
- Climbs over curbs up to 4 inches
- Safely and effectively climbs and descends ramps up to 10˚
- Off road traction capability
- Multiple programming options
- Solid, secure and safe brake action
- Low shearing system during transition to standing
- Engineered chairs and biomechanics in all seating and standing positions
- Low seat height for transfer and driving under tables
- Easily adjusted to individual body measurements
- Power elevating legrest
- Low shear back support
- Easily adapts to any back support
- Maximum safety in all positions
- Compact maneuverability for tight spaces
- High battery capacity
- Highly configurable to suit individual needs
- Different colour and size options available
Specifications
| Code(s) | 0400-0010 | 0400-0020 | 0400-0030 | 0400-0050 |
| Option | Tilt/400mm | Tilt/480mm | Multifunction/400mm | Multifunction/480mm |
| Seat depth | 350 - 630mm | 350 - 630mm | 350 - 630mm | 350 - 630mm |
| Seat width - 40mm increments | 320 - 520mm | 320 - 520mm | 320 - 520mm | 320 - 520mm |
| Total chair width | 630mm | 630mm | 630mm | 630mm |
| Backrest height | 410mm | 410mm | 410mm | 410mm |
| Seat height | 480 or 540mm | 480 or 540mm | 480 or 540mm | 480 or 540mm |
| Armrest height | 150 - 360mm | 150 - 360mm | 150 - 360mm | 150 - 360mm |
| Total height | 1000mm | 1000mm | 1000mm | 1000mm |
| Safe working load | 140kg | 140kg | 140kg | 140kg |
| Chair weight | 185kg | 185kg | 185kg | 185kg |
| Maximum curb climbing | 100mm | 100mm | 100mm | 100mm |
| Maximum safe slope | 10° | 10° | 10° | 10° |
| Range - 73 Ah batteries | 35km | 35km | 35km | 35km |
| Range - 48 Ah batteries | 25km | 25km | 25km | 25km |
| Total chair length | 1100mm | 1100mm | 1100mm | 1100mm |
| Turning circle | 1170mm | 1170mm | 1170mm | 1170mm |
| Speed | 6, 8 or 10km/h | 6, 8 or 10km/h | 6, 8 or 10km/h | 6, 8 or 10km/h |
User Manual
Information sheet
Key features
- Four powered wheels for superior traction and agility
- Climbs over curbs up to 4 inches
- Safely and effectively climbs and descends ramps up to 10˚
- Off road traction capability
- Multiple programming options
- Solid, secure and safe brake action
- Low shearing system during transition to standing
- Engineered chairs and biomechanics in all seating and standing positions
- Low seat height for transfer and driving under tables
- Easily adjusted to individual body measurements
- Power elevating legrest
- Low shear back support
- Easily adapts to any back support
- Maximum safety in all positions
- Compact maneuverability for tight spaces
- High battery capacity
- Highly configurable to suit individual needs
- Different colour and size options available
| Code(s) | 0400-0010 | 0400-0020 | 0400-0030 | 0400-0050 |
| Option | Tilt/400mm | Tilt/480mm | Multifunction/400mm | Multifunction/480mm |
| Seat depth | 350 - 630mm | 350 - 630mm | 350 - 630mm | 350 - 630mm |
| Seat width - 40mm increments | 320 - 520mm | 320 - 520mm | 320 - 520mm | 320 - 520mm |
| Total chair width | 630mm | 630mm | 630mm | 630mm |
| Backrest height | 410mm | 410mm | 410mm | 410mm |
| Seat height | 480 or 540mm | 480 or 540mm | 480 or 540mm | 480 or 540mm |
| Armrest height | 150 - 360mm | 150 - 360mm | 150 - 360mm | 150 - 360mm |
| Total height | 1000mm | 1000mm | 1000mm | 1000mm |
| Safe working load | 140kg | 140kg | 140kg | 140kg |
| Chair weight | 185kg | 185kg | 185kg | 185kg |
| Maximum curb climbing | 100mm | 100mm | 100mm | 100mm |
| Maximum safe slope | 10° | 10° | 10° | 10° |
| Range - 73 Ah batteries | 35km | 35km | 35km | 35km |
| Range - 48 Ah batteries | 25km | 25km | 25km | 25km |
| Total chair length | 1100mm | 1100mm | 1100mm | 1100mm |
| Turning circle | 1170mm | 1170mm | 1170mm | 1170mm |
| Speed | 6, 8 or 10km/h | 6, 8 or 10km/h | 6, 8 or 10km/h | 6, 8 or 10km/h |
User Manual
Information sheet
